high temperature industrial gas pressure regulator

  • 1 - 199 Sets
    $200.00
  • >=200 Sets
    $188.88
Material:
Stainless Steel
Pressure:
Medium Pressure
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
AFK
Model Number:
R31
Application:
Other
Power:
Solenoid
Temperature of Media:
Normal Temperature
Structure:
Diaphragm
Media:
Gas
Port Size:
1/4"NPT
Body thread:
3/4"NPT(F)
Maximum input pressure:
500 and 1500 PSI
Output pressure:
0-15 , 0-25, 0-75, 0-125PSI
working temperature:
-40℃-----+70℃
Cv:
1.8
valve seat:
PCTFE , PTFE
weight:
2.7kg
Supply Ability
Supply Ability:
10000 Set/Sets per Week
Packaging & Delivery
Packaging Details
export packing
Port
shenzhen







Detailed Product Description
Material:316L SSMaximum Inlet Pressure:3000, 500psig
Output Pressure:0~25, 0~50, 0~100, 0~250psigWorking Temperature:-40~+74 Deg C
Applied Gas:High Pure Gases, Standard Gases, Corrosive Gases And So OnPort:Shenzhen




Technical Parameter:



Maximum Inlet Pressure                       500,3000psig
Outlet Pressure Ranges  0~25, 0~50, 0~50,0~250,0~500psig
Safety test pressure1.5 times maximum inlet pressure

Operating Temperature

-40°F to +165°F / -40°c to 74°c

Leakage Rate Against Atmosphere

2*10-8atm cc/sec he
Cv value0.06
  • Material:



     Body                              316L.Brass
    Bonnet316L. Brass
    Diafragm316L
    Strainer316L(10 μm)
    SeatPCTFE,PTEE, Vespel
    Spring316L
    Plunger valve core316L



    Design Feature:



     Single-stage pressure reducer

    Maternal and diaphragm use hard seal form

    Body NPT:inlet and outlet interface 1/4''NPT(F)

    The internal structure easy to purge

    Can set filters

    Can use a panel Intallation

    Inlet form:Needle valve, membrane valve



    Typical Applications:



    Labotary

    Gas Chromatography

    Gas laser

    Gas bus-bar

    petro-chemical industry

    Test equipment
